Endress+Hauser TMT112-A1KCA Temperature transmitter

Endress+Hauser iTEMP TMT112 Overview

The Endress+Hauser iTEMP TMT112 is a cost-effective temperature transmitter used to convert various Resistance Temperature Detector (RTD) and Thermocouple (TC) input signals into a stable analog output signal (typically 4...20 mA). It is designed for standard industrial temperature measurement applications. The suffix "A1KCA" indicates a specific configuration.

Product Detailed Description

• Function:

• Accepts input signals from Resistance Temperature Detector (RTD) or Thermocouple (TC) temperature sensors.

• Linearizes and converts this temperature signal into a standard 4...20 mA analog output signal.

• Provides a reliable and economical temperature measurement solution.

• Supports various RTD types (e.g., Pt100) and TC types (e.g., K, J, T, E, N, R, S, B).

• Offers configurable measuring ranges.

• Features a compact design suitable for field or DIN rail mounting.

• Features:

• Universal input for various RTD and TC types.

• 2-wire technology for simplified wiring and power supply.

• Configuration via PC or handheld programmer.

• High reliability and accuracy.

• Cost-effective solution.

• Fault signal according to NAMUR NE43.

• EMC conformity according to NAMUR NE21.

Product Parameters

As the specific model suffix (e.g., A1KCA) indicates a particular configuration, the following are some typical parameters for the iTEMP TMT112. Always refer to the official datasheet for the specific model for accurate parameters:

• Input:

• RTD: Pt100 (standard), Pt1000, Ni100, Ni1000, etc. (configurable).

• TC: Type J, K, T, E, N, R, S, B, etc. (configurable).

• Output:

• Analog output: 4...20 mA, 2-wire.

• Measuring Range:

• Configurable, depending on the sensor type and selected range.

• Accuracy:

• Typically ±0.2% of the measuring span or better (depending on configuration).

• Supply Voltage:

• 10...35 V DC (2-wire).

• Ambient Temperature:

• Operating temperature range typically -40 °C to +85 °C.

• Storage temperature range typically -40 °C to +85 °C.

• Protection Degree:

• Typically IP20 (with terminal block).

• EMC:

• According to NAMUR NE21.

• Fault Signal:

• According to NAMUR NE43 (configurable high or low).

• Connection:

• Pluggable terminal blocks.

• Mounting:

• Suitable for connection to sensor heads or DIN rail mounting.

Product Advantages

• Versatility:

• Supports a wide range of RTD and TC types, reducing inventory needs.

• Cost-Effective:

• Offers reliable performance at a competitive price.

• Easy Configuration:

• Simple configuration via PC or handheld programmer.

• 2-Wire Technology:

• Simplifies wiring and reduces installation costs.

• High Reliability:

• Endress+Hauser is a well-known manufacturer of industrial instrumentation with reliable product quality.

• Compliance with Industrial Standards:

• Complies with NAMUR NE43 and NE21 standards.

Precautions

• Correct Selection:

• Choose the appropriate model based on the required sensor type, measuring range, and application needs.

• Correct Installation:

• Follow Endress+Hauser's installation guidelines, ensuring the transmitter is securely mounted and correctly wired.

• Sensor Connection:

• Ensure the RTD or TC sensor is correctly connected to the transmitter's input terminals.

• Power Supply Requirements:

• Use a DC power supply that meets the specifications.

• Configuration:

• Configure the transmitter correctly according to the specific sensor type and measuring range before commissioning.

• Environmental Conditions:

• Avoid using the transmitter in environments exceeding its operating temperature range.

• EMC Considerations:

• Follow EMC guidelines for installation and wiring to ensure electromagnetic interference resistance.

Product Applications

The Endress+Hauser iTEMP TMT112 is widely used in various industrial sectors for basic temperature measurement:

• General Industrial Applications:

• Temperature monitoring of machines and equipment.

• Process temperature measurement.

• Heating, Ventilation, and Air Conditioning (HVAC):

• Temperature monitoring of pipes and equipment.

• Food and Beverage Industry:

• Simple process temperature measurement.

• Water and Wastewater Treatment:

• Temperature monitoring of tanks and pipes.

• Pharmaceutical Industry:

• Temperature measurement in non-critical processes.
